SSP 8

Typical Applications

Pump clean water with sand content <150g/m³ for diverse applications.
Extract water efficiently from wells for various agricultural needs.
Utilize the pump for river-based water extraction and distribution purposes.
Support farm irrigation systems, ensuring optimal water supply for crops.
Provide reliable water supply solutions for various domestic and industrial uses.
Facilitate efficient water extraction in mining operations for diverse applications.
Aid in drainage systems within the breeding industry for optimal conditions.

Operating Conditions

Motor

Material Specifications

Components	Material
Pump body	Stainless steel
Pump shaft	Stainless steel
Impeller	POM
Bearing	C&U
Mechanical seal	Ceramic/Graphite, SIC/Graphite or Alloy
Coupling and outlet	Brass, Stainless steel
Shaft coupling	AISI304 SS
Motor shaft	AISI304 SS
Oil chamber	Cast iron

TechnicalData

Model	Motor		Dimensions (mm)			Weight (kg)		Recommended Satte Controller (kW)
Model	KW	HP	P	M	T	P	M	Recommended Satte Controller (kW)
SSP 8/5	0.55	0.75	398	378	720	3.3	8	0.75
SSP 8/7	0.75	1	473	398		3.7	8.7	1
SSP 8/10	1.1	1.5	550	438	940	4.3	10.8	1.5
SSP 8/12	1.5	2	695	515	1162	5.2	13.8	2
SSP 8/17	2.2	3	886	590	1428	6.8	17.4	3
SSP 8/21	3.0	4	1040	605	1596	7.8	19.3	4
SSP 8/26	4.0	5.5	1262	723	1937	9.4	21.9	5.5
SSP 8/31	5.5	7.5	1453	813	2218	11.2	25.6	7.5
SSP 8/37	7.5	10	1713	903	2568	12.8	28.3	10

Product Video

Datasheet/Downloads SSP 8 Datasheet
