| PARAMETER |
S200Ah — 24 V / 200 Ah |
|
| ELECTRICAL |
| Nominal Voltage |
25.6 V |
51.2 V |
| Rated Capacity |
200 Ah |
100 Ah |
| Nominal Energy |
5.12 kWh |
5.12 kWh |
| Operating Voltage Range |
21.6 – 28.8 V |
43.2 – 57.6 V |
| Cell Chemistry |
Lithium iron phosphate (LiFePO4) |
Lithium iron phosphate (LiFePO4)
|
| Cell Configuration¹ |
1P 8S |
1P 16S |
| Depth of Discharge² |
98 % (BMS limit) |
98 % (BMS limit) |
| CHARGE & DISCHARGE |
| Nominal Charging Current |
100 A |
40 A |
| Nominal Charging Power³ |
≈ 2.56 kW |
≈ 2.05 kW |
| Nominal Discharging Current |
100 A |
60 A |
| Continuous Discharge Power³ |
≈ 2.56 kW |
≈ 3.07 kW |
| BANK CONFIGURATION |
| Modules in Series |
Not permitted — parallel connection only |
Not permitted — parallel connection only
|
| Modules in Parallel |
Permitted. Maximum is set by the inverter — see the inverter datasheet |
Permitted. Maximum is set by the inverter — see the inverter datasheet
|
| Typical Maximum in Parallel⁴ |
4 modules (20 kWh) on SNM-ECO / TURBO; 8 modules (41 kWh) on MAX |
4 modules (20 kWh) on SNM-ECO / TURBO; 8 modules (41 kWh) on MAX
|
| INVERTER COMPATIBILITY |
| Maximum Inverter Rating, One Unit³ |
2.4 kW |
2.9 kW |
| Units Required — SATTE SNM-ECO 3.6KW |
2 |
2 |
| Units Required — SATTE SNM-ECO 4.2KW / SINV-4.2KW |
2 |
2 |
| Units Required — SATTE SNM-ECO 6.2KW / SINV-6.2KW |
— |
3 |
| Communication Protocol |
Pylontech · Deye/Sunsynk · Growatt · GoodWe · Victron · SofarSolar · LuxPower · Solis · SMA · SRNE · Outback · AlphaESS |
Pylontech · Deye/Sunsynk · Growatt · GoodWe · Victron · SofarSolar · LuxPower · Solis · SMA · SRNE · Outback · AlphaESS
|
| ENVIRONMENTAL |
| Charging Temperature Range |
0 °C to +45 °C |
0 °C to +45 °C |
| Discharging Temperature Range |
−20 °C to +60 °C |
−20 °C to +60 °C |
| Relative Humidity |
≤ 95 %, non-condensing |
|
| Maximum Operating Altitude |
2000 m |
2000 m |
| Cooling Method |
Natural convection |
|
| Ingress Protection |
IP54 |
IP54 |
| INTERFACE |
| Communication Ports |
RS485 / RS232 / CAN |
|
| Display |
LED status indicator |
|
| MECHANICAL |
| Dimensions (H × W × D) |
565 × 480 × 180 mm |
|
| Dimensions (inches) |
22.3 × 18.9 × 7.1 in |
|
| Weight |
51.0 kg (112.4 lb) |
|
| Mounting |
Wall-mounted, indoor |
|
| CERTIFICATION |
| Transport Certification |
UN38.3 / MSDS / DGM |
|
