SFLO SD

Applications

Ideal for water supply in off-grid and remote locations where traditional power sources are unavailable.
Suitable for irrigation systems in fields and farms, enhancing water access efficiency.
Provides a reliable water source for rural communities, promoting sustainable development.
Useful for emergency situations, offering a solar-powered solution for temporary water supply needs.
Adaptable to varying environmental conditions, offering flexibility in deployment for different climates and terrains.

Operating Conditions

Non-corrosive water; the volume ratio al sand content no more than 3%; particle size less than Imm
Max medium temperature up to +40°C; PH value remains 5-10
Work close to the rated head and must be immersed in water.

Pump Specifications

Model	W	Current (A)	Rated motor voltage	Solar Array Voltage (V)	controller Max Voltage(V) Input Voltage(V)	Max Input Voltage (V)	Peak Voltage (V)	Rated Motor Voltage	Open Circuit Voltage (VOC)	PV Modules (W)	DN (")	Length (mm)	Width (mm)	Weight (kg)
SFLO SD E400	400	8.3	48v	50V-70V	96	100	≥50	48	<100	1x450W LV X1 Array	1.25"	76	1020	17
SFLO SD E600	600	12.5	48v	50V-70V	96	100	≥60	48	<100	2x450W LV X1 Array	1.25"	102	658	34
SFLO SD E800	800	16.5	48v	50V-70V	96	200	≥60	48	<200	2x450W LV X1 Array	100	860	21
SFLO SD E1000	1000	13.8	72V	80V-110V	150	350	≥112	72	<350	2x450W LV X1 Array	2"	125	764	38

Product Video

Datasheet/Downloads SFLO SD Datasheet
